16 Channel Remote Control Receiver+Transmitter
Wireless Remote Control 12/24V 16 Channels 868MHz
Universal radio controller with wireless remote control - primarily used in hydraulics and pneumatics.
It is used for remote control of up to 8 sections in hydraulic distributors and winches, but it also finds application in electrical systems where remote control of up to 16 electrical installation elements is required.
The set includes:
- Casing with receiver (hermetic box)
- Two-button wireless remote control (transmitter)
Each controller is coded during production (the serial number is visible on the controller and receiver housing) to be compatible with only one wireless controller included in the set.
The remote control is protected against unwanted, accidental pressing - it is unlocked by a sequence of the first two buttons from the first row:
Pressing the left and right upper arrow buttons simultaneously for three seconds unlocks the remote control and makes it ready for use.
To lock it again, press the OFF button or wait approximately 2 minutes from the last button press.
| Category: | Plošina |
|---|---|
| Weight: | 1.3 kg |
| Napětí: | 12/24V |
| Voltage: | 12 / 24 V |
| Working frequency: | 868,32mhz |
| Operating temperature: | -20-+60°C |
| Number of radio channels: | 16 |
| Modulation type: | FSK |
| Coding :: | Unique serial number |
| Operating mode: | Monostable |
| Activation time: | 30 ms |
| Receiver dimensions: | 180X150X80mm |
| Remote control dimensions: | 90X150X26mm |
| Remote control power supply: | 2X 1,5 V R03 AAA baterie |
| 24-hour relay activation: | 40 ms |
